1
6-4722 0309 02
CRANK HOUSING ALH/SHL 25
2
6-4722 2001 02
CRANK SHAFT ALH/SHL 25
4
6-4722 0935 01
LEVEL WINDOW
5
6-4722 0311 02
BEARING COVER ALH/SHL 25
6
6-4722 0312 01
WASHER BEARING ALH/SHL 25
7
6-4722 0313 02
BEARING FLANGE
8
6-4722 0752 01
SPACER RING ALH/SHL 25 (SZO 18
11
6-4722 6786 01
BELLOW RING REAR
13
6-4931 8090 09
FILLER CAP 1.5
14
6-4722 0407 80
OIL SCRAPER ALEX 25
16
6-4722 5174 01
Винт. SCREW
18
90459-0277
Screw Hex.Sock.Set Conept.MS6SS M6x30 A2
19
312105-0455
SCREW, M6S ISO 4017 M8X30 A4 80
20
312101-0538
Screw M6S M12x35 fzb
22
312101-0536
Screw M6S M12x30 fzb
23
6-4300 0018 04
SEALING RING 18 x 22 DIN 7603
24
312101-0545
Screw M6S M12x65 fzb
26
315401-0178
WASHER FBH12,2FZB
30
6-4301 5000 11
Прокладка. GASKET
31
6-4722 5181 01
SEAL 21 x 26 x 1.5
32
315202-0241
Уплотнительное кольцо O-Ring 119,3x5,7 mm
33
6-4302 0205 01
Уплотнительное кольцо O-RING 205 x 4
34
6-4302 0490 56
Уплотнительное кольцо O-RING 312 x 4
35
6-4302 0105 00
Уплотнительное кольцо O-RING 105 x 4
40
6-4016 0302 70
CIRCLIP 270 x 5 DIN 472
41
6-4016 0302 15
CIRCLIP 215 x 5 DIN 472
42
6-4241 2200 04
ROLLER BEARING RIGHT ALEX 25 NUP224
43
6-4241 0204 10
ROLLER BEARING LEFT ALEX 25 NU230
44
6-4305 0015 00
SEALING BOX 150 x 180 x 15 DIN 3760
51
6-4648 0000 05
PLUG 10.7
54
312104-0506
Screw M6S M10x75H fzb
55
312601-0320
NUT M6M 10-8 FZB
60
315105-0165
FWAS080G0-0S, WASHER PLAIN
61
6-4722 8055 01
Рамка. FRAME
62
6-4722 1988 01
BELLOW
64
6-4722 5538 06
HOSE CLAMP 124-135
67
6-4722 2455 02
Плита. PLATE
82
6-4722 1992 80
CONNECTING ROD COMPLETE ALEX 25
83
6-4722 2022 01
CROSS HEAD ALEX 25
84
6-4722 2453 04
CROSS HEAD BOLT
85
6-4722 2162 01
PLAIN BEARING ALEX 25
86
6-4722 5356 01
LOCK NUT M6M Tri-loc 16 DIN 6925
87
6-4722 5251 01
SCREW 6x16, 8.8 FZB DIN 6912
15
6-4722 8293 01
OIL COOLER SS TA25
17
90030-0096
CONN. ELBOW W-12
